Mascot 9262 81W 24V/13.2V Switch mode DC/DC converter with electrical separation and Regulated output
In stock
PDL Code
PDL19262241200
£122.69
£102.24
A Switch mode DC/DC converter with a regulated output, the input electrically separated from the output and Maximum power of 81W with protection including reverse Voltage, overvoltage, short circuit and thermal protection. The converter switches off at voltages over or under the specified range. The converter is CE and E marked. This converter is specifically designed for electric forklift trucks and other electromotive applications where high transients may occur.
| Model | 9262 |
|---|---|
| Type | Switch Mode |
| Manufacturer | Mascot |
| Product Code | PDL19262241200 |
| MPN | 9262241200 |
| Maximum Power | 81W |
| Input Voltage | 21-32V DC |
| Continuous Load Current | 6A |
| Output Voltage | 13.2V DC |
| Regulated Output | Regulated |
| Electrical Separation | Yes |
| Input Terminals | 6.3mm Push on |
| Output Terminals | 6.3mm Push on |
| Weight | 600g |
| CE & E Marked | CE and E Marked |
| Datasheet | https://mascot.no/media/1225/9262-tech-spec.pdf |
| Declaration of Conformity | https://mascot.no/media/1916/mascot-9262-doc-2019_06.pdf |
