Mascot 9063 40W 24V/13.5V Linear DC/DC converter with regulated output with Backup

In stock
PDL Code
PDL19063241200
£53.53 £44.61

This product has now been discontinued and is only available whilst stock lasts. Pulsar recommend PDL19062241200   as a suitable alternative. Please contact us if you require further assistance.



A Linear DC/DC converter with back up and a regulated output and Maximum power of 40W with the input protected against reverse Polarity and the output with overvoltage protection. The converter is E marked and specially designed for car stereo equipment
Product Specification
Model 9063
Type Linear
Manufacturer Mascot
Product Code PDL19063241200
MPN 9063241200
Maximum Power 40W
Input Voltage 20-32V DC
Continuous Load Current 3A
Output Voltage 13.5V DC ( Backup 14.5V DC)
Regulated Output Regulated
Electrical Separation No
Input Terminals 6.3mm Push on
Output Terminals 6.3mm Push on
Weight 400g
CE & E Marked E Marked ( 95/54/EC)
Datasheet https://mascot.no/media/1222/9063-tech-spec.pdf
Declaration of Conformity https://mascot.no/media/1033/9063-doc.pdf
