Mascot 9660 168W 48V/20-28V Switch mode DC/DC converter with electrical separation and Regulated output

In stock
PDL Code
PDL19660482400
£205.93 £171.61

A Switch mode DC/DC converter with a regulated output, the input electrically separated from the output and Maximum power of 158W with protection including reverse Voltage, overvoltage, short circuit and thermal protection. The converter switches off at voltages over or under the specified range. The converter is CE and E marked. This converter is specifically designed for electric forklift trucks and other electromotive applications where high transients may occur.
Product Specification
Model 9660
Type Switch Mode
Manufacturer Mascot
Product Code PDL19660482400
MPN 9660482400
Maximum Power 168W
Input Voltage 40-120V DC
Continuous Load Current 7A
Output Voltage Adjustable 20 to 28V DC
Regulated Output Regulated
Electrical Separation Yes
Input Terminals 6.3mm Push on
Output Terminals 6.3mm Push on
Weight 1.1Kg
Datasheet https://mascot.no/media/1227/9660-tech-spec.pdf
Declaration of Conformity https://mascot.no/media/1055/9660-doc.pdf
